Stud Wall Spacing In The UK: 400 Vs 600 mm Centres, Noggin Rules & Fixings

Stud walls look easy, a frame of timber, plasterboard on both sides, done. But anyone who’s ever had to hang a radiator or align plasterboard joints knows the devil’s in the spacing.

Whether you opt for 400 mm or 600 mm centres, the choice can make the difference between a solid wall and one that flexes, cracks, or simply doesn’t line up.

For UK builders, joiners, and dryliners, getting stud spacing right isn’t just about habit. It affects board fit, acoustic performance, strength, and even compliance.

This guide gets into the reasoning behind common stud layouts, noggin placement, and fixing techniques, from a trade perspective.

What A Stud Wall Actually Is?

A stud wall is basically a skeleton made from timber or metal sections that forms the framework for internal walls.

In the UK, timber companies use CLS (Canadian Lumber Standard) timber in sizes like 38×63 mm or 38×89 mm, depending on height and load.

Metal stud walls use C-studs and U-tracks, often seen in commercial fit-outs or lightweight partitions.

Both types are the same principle, vertical studs fixed between a head plate at the top and a sole plate at the bottom, with noggins running horizontally to stiffen the frame.

Not all stud walls are load-bearing. Many are just partitioning, separating rooms or services. But even non-structural walls must withstand the stresses of fixtures, doors, and thermal or acoustic lining.

Standard Stud Spacing In The UK

When someone says “400 mm centres,” they mean the distance from the centre of one stud to the centre of the next, not edge to edge.

That matters because plasterboard sheets (usually 1,200 mm wide) are designed to fit neatly with standard spacing.

In the UK, most walls are framed at either 400 mm or 600 mm centres, occasionally 450 mm for certain board layouts or curved walls.

Those figures aren’t arbitrary; they come from building standards and plasterboard manufacturer recommendations like British Gypsum and Knauf.

At 600 mm centres, a standard 1,200 mm board will fit across three studs, centre, joint, and edge. At 400 mm centres, the board edges will fall on every second stud, giving tighter support and less board deflection.

Accuracy matters here. A few mm out at each stud can throw the whole wall out, and you’ll be fighting gaps when it’s time to board up. Good tradespeople always double-check the spacing from the centre line, not just “by eye”.
